RP-12 Nylon™



Features:
  • Easy to splice
  • Excellent wear characteristics
  • High strength
  • Mitigates shock
  • Pro-Gard Marine Finish
Applications:
  • General Working Line /
    Vessel Mooring
  • Lifting Sling / Offshore
  • Mooring Pendant
  • Secondary Mooring Line
  • Shock Line
  • Trawl or Bridle Line
  • Working Line / Offshore
Specifications:

Product Code:323

Fiber (Core/Cover):Nylon

Specific Gravity:1.14

Splice:Round Plait Class I

Manufacturer:Samson Rope Technologies, Inc.

*ISO strength specifications are for unspliced rope. All other strength specifications are for spliced rope.
Additional sizes available. Contact Customer Service for details.

Download Product PDF
Diameter (inch) Circumference (inch) Weight Per 100 Ft. (lbs) Avg. Strength (lbs) Min. Strength (lbs) Diameter (mm) Circumference (mm) Weight Per 100m (kg) Avg. Strength (kg) Min. Strength (kg) ISO 2307 Strength (metric tons)
3/4 2-1/4 15.0 17,700 15,000 18 54 22.3 8,000 6,800 7.6
7/8 2 3/4 22.6 27,600 23,500 22 66 33.6 12,500 10,600 11.8
1 3 26.3 34,400 29,200 24 72 39.1 15,600 13,300 14.7
1-1/8 3-1/2 33.8 40,400 34,300 28 84 50.3 18,300 15,600 17.3
1-1/4 3-3/4 39.5 47,000 40,000 30 90 58.8 21,300 18,100 20.1
1-5/16 4 45.1 53,500 45,500 32 96 67.1 24,300 20,600 22.9
1-1/2 4-1/2 56.4 66,500 56,500 36 108 83.9 30,200 25,600 28.5
1-5/8 5 67.7 79,500 67,600 40 120 101 36,100 30,700 34.1
1-3/4 5-1/2 79.0 92,400 78,500 44 132 118 41,900 35,600 39.6
2 6 95.9 117,000 99,500 48 144 143 53,100 45,100 50.1
2-1/8 6-1/2 113 131,000 111,000 52 156 168 59,400 50,500 56.1
2-1/4 7 135 154,000 131,000 56 168 201 69,800 59,300 65.9
2-1/2 7-1/2 152 175,000 149,000 60 180 226 79,600 67,600 75.1
2-5/8 8 169 194,000 165,000 64 192 251 88,100 74,900 83.2
2-3/4 8-1/2 192 232,000 197,000 68 204 286 105,000 89,500 99.4
3 9 220 257,000 219,000 72 216 327 117,000 99,200 110
3-1/4 10 271 307,000 261,000 80 240 403 139,000 118,000 132
3-5/8 11 321 375,000 319,000 88 264 478 170,000 145,000 161
3-3/4 11-1/4 355 416,000 354,000 92 272 528 189,000 160,000 178
4 12 389 444,000 377,000 96 288 579 201,000 171,000 190
4-1/8 12-1/2 423 488,000 415,000 100 300 629 221,000 188,000 209
4-1/4 13 457 518,000 440,000 104 312 680 235,000 200,000 222
4-5/8 14 525 579,000 492,000 112 336 781 263,000 223,000 248
5 15 658 686,000 583,000 120 360 979 311,000 264,000 294
5-1/4 16 725 819,000 696,000 128 384 1,079 371,000 316,000 351
5-5/8 17 832 929,000 790,000 142 426 1,238 421,000 358,000 398
6 18 948 1,037,000 881,000 152 456 1,411 470,000 400,000 444
6-1/4 19 1,028 1,102,000 937,000 158 474 1,530 500,000 425,000 472
6-5/8 20 1,155 1,242,000 1,056,000 168 504 1,719 563,000 479,000 532
